The TempAir THP-Series direct-fired make-up air heaters work well in most types of construction applications, helping to control moisture and air contaminants. These heaters operate similar to a permanent air handler, providing evenly distributed, warm, dry air. Installed either inside or outside, THP-Series heaters draw 100% fresh air through the unit’s intake and discharge tempered air controlled by a remote thermostat.
Features:
- Electronic modulating burner controls and remote space thermostats adjust gas flow, saving money on fuel costs
- A centrifugal blower provides large volumes of air and high static pressures allowing the equipment to work well with ductwork when needed
Equipment Specs
| MODEL | BTU/HR MAXIMUM | CFM | POWER SUPPLY |
|---|---|---|---|
| THP-300 FULL DETAILS | 30,780 – 300,000 | 1,900 | 115/1/60/20 |
| THP-400 FULL DETAILS | 80,000 – 400,000 | 2,400 | 115/1/60/20 |
| THP-500 FULL DETAILS | 40,300 – 500,000 | 2,800 | 115/1/60/20 |
| THP-550 FULL DETAILS | 40,500 – 550,000 | 3,000 | 115/1/60/20 |
| THP-750 FULL DETAILS | 43,200 – 750,000 | 4,000 | 230/1/60/15* |
| THP-1000 FULL DETAILS | 48,600 – 1,000,000 | 6,000 | 230/1/60/25* |
| THP-1400 FULL DETAILS | 60,750 – 1,400,000 | 7,600 | 230/1/60/25* |
| THP-2000 FULL DETAILS | 89,100 – 2,000,000 | 11,000 | 460/3/60/10* |
| THP-3000 FULL DETAILS | 133,650 – 3,000,000 | 16,500 | 460/3/60/15* |
| THP-4000 FULL DETAILS | 170,000 – 4,000,000 | 21,000 | 460/3/60/20* |
| THP-4500 FULL DETAILS | 202,500 – 4,500,000 | 24,500 | 460/3/60/30* |
